QC-930 Automatic reel paper Die cutting machine
-
Description
Remarks:
1). Price term: FOB Ningbo.
2). Payment: Pay by T/T or L/C.
3). Delivery time: Within 60 days after receipt of advance.
4). Packaging: Seaworthy packing.
5). Engineer service and after sale service: Spare parts guarantee for one year, and we can send technician for installation and training at the cost of buyer.
Machine VideoWelcome to Wenzhou Qichen Industry & Trade Co.,Ltd.
Brief Description:
QC-930 High speed automatic reel paper die-cutting machine is the professional equipment which uses for cutting various kind of popular paper and pe coated paper, be applicable to printing, packaging, paper cup and other to the die cutting area, cutting length can be set in touch-screen, it is convenience and precise. And it can die-cut the blank paper and printed paper.
Main technical Data
Max. area of creasing: 930×530mm
Press cut line length:＜250mm
Working speed: 80-120times/min
Main motor power: 7.5kw
Applicable paper: 150-450g/m2
Air source: 1.0m3/min
Weight: 8Ton
Dimension: 4550×2100×1700mm
Quotation
| No. | Name | Model | Quantity | Unit Price | Amount |
| (Set) | (USD) | (USD) | |||
| 1 | High speed automatic reel paper die cutting machine | Qc-930 | 1 | ||
| EXTRA moulds | 1 |
| Max Roll Diameter | φ1600mm |
| Max Cutting Size | 910*520 mm |
| Precision | ±0.25 |
| Max Cutting Press | 200 Ton |
| Max Cutting Speed | 130 cut/min |
| Paper Material | 130-400gsm |
| Weight | 7.5 T |
| Total Power | 15KW |
| Dimension | 5000*3100*1950 mm |
| Item | Brand |
| Servo Motor |  |
| Servo Driver | |
| PLC | |
| PLC | |
| 7.5kw Converter | |
| 1.5kw Converter | |
| 7 Touch Screen |  |
| Sensor |  |
| Low-Voltage Apparatus |  |
